MVME5110 VMEbus processor module

Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!

Hardware Architecture

• Processor: Adopts MPC7410 or MPC750 microprocessors with 32KB/32KB L1 cache.
• Memory
  • SDRAM: On-board ECC SDRAM has a maximum capacity of up to 512MB, and can be expanded to 1.5GB through the optional RAM500 memory expansion module.
  • Flash: Equipped with 17MB of flash memory, which is used to store programs, data, etc.
  • NVRAM: Features 32KB of Non-Volatile Random Access Memory (NVRAM), as well as a real-time clock with a replaceable battery backup. This ensures that key configuration information and time data can still be saved after the system is powered off.

• Cache: Has a secondary back-end cache of up to 2MB, which can speed up data access and improve system performance.
• Expansion Slots
  • PMC Slots: Comes with dual IEEE P1386.1 compatible 32/64-bit PMC expansion slots. These can be used to connect various PMC modules, such as communication modules and data acquisition modules, to expand system functions.
  • PCI Expansion: Provides a 64-bit PCI expansion mezzanine connector, which can connect up to four more PMC modules, further enhancing the scalability and flexibility of the system.

Interface Types

• Serial Ports: Equipped with two 16550-compatible asynchronous serial ports. These can be used to connect external devices such as modems and terminal devices to achieve serial data communication.
• Ethernet Ports: Has dual 10BaseT/100BaseTX Ethernet interfaces that support Ethernet communication protocols. They can easily connect to other devices via a network to realize data transmission and remote control.

Performance Features

• High-Speed Data Transmission: Based on Emerson’s designed integrated PCI bridge-memory controller ASIC, the PowerPlus II architecture enables a memory read bandwidth of 582MB/s and a burst write bandwidth of 640MB/s. It also supports the full PCI throughput of 264MB/s, ensuring high-speed data transmission between the processor, memory, and peripherals, and avoiding data congestion.
• High Reliability: The SDRAM using ECC (Error Checking and Correction) technology can detect and correct data errors in the memory, improving the stability and reliability of the system. In addition, the device has circuit protection functions, including overvoltage, overcurrent, and overheating protection, which can effectively protect the circuit board from damage.

Warranty： 365 days
Quality: Original module
Condition： New / Used
Warehouse: Spot
Delivery time: Shipped in 3 days after payment
