IS200VRTDH1D Mark VI IS200 series control board
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IS200VRTDH1D essential information:
Manufacturer: General Electric (GE).
Belonging to the Mark VI IS200 series.
Type: VME RTD (Resistance Temperature Device) card.
Functional features:
Specially used for temperature measurement, supporting RTD sensor input, it can convert analog input signals from RTD sensors into digital temperature values, providing temperature monitoring data for industrial automation systems, and is a key component for turbine temperature control and monitoring.
It has 16 channels and can handle 16 three wire RTD inputs, but the inputs are not directly connected to the board. They are first connected to the RTD terminal board and then connected to the VME rack where the card is installed through cables.
Using a 14 bit resolution A/D converter to ensure high accuracy in temperature measurement.
The panel has three LED indicator lights (green, red, orange) to indicate operation/malfunction/status.
Technical parameters:
Working voltage: usually 24V DC (some data shows that there are different terms such as 220V, but 24V DC is commonly used).
Power consumption: less than 12 watts.
Storage temperature: -40 to+70 ° C.
