IS200TREGH1BEC printed circuit board
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IS200TREGH1BEC is a printed circuit board produced by General Electric (GE), belonging to the Mark VI IS200 series, commonly used in industrial automation, power generation, and control systems. Here is its detailed information:
Functional purpose: It is a board component in the Mark VI or Mark VIe Speedtronic system, associated with the Emergency Turbine Protection Board (VPRO), which helps provide independent emergency overspeed protection. It is used to provide a positive pole for the 125 VDC trip function, and another board is used to provide a negative pole, which can control the trip solenoid valve to achieve trip protection in case of emergency situations in the turbine.
Hardware composition: There are a total of twelve relays on the surface, nine of which are used to form three groups of three relays each, to vote on the input for controlling the trip solenoid valve. It also has twelve metal oxide varistors, multiple jumpers, integrated circuits and transistors, as well as three D-type shell connectors for cable connections, two terminal blocks, and several other female plug connections.
