IS200TPROS1CBB Mark VIe Control System Processor Module
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IS230TBAIH2C is an analog input/output module produced by General Electric (GE), belonging to the Mark VI series, used for GE Speedtronic gas turbine control systems. Here is its detailed information:
Specification parameters
Number of channels: 12 channels, of which 10 are analog input channels and 2 are analog output channels.
Input signal range: Supports multiple input signal types, such as 1-5V DC voltage input, and can also be configured as other types of input signals through jumper wires, such as ± 5V, ± 10V DC, etc. It can also be connected to two-wire, three wire, four wire or externally powered transmitters.
Hardware design: It is a printed circuit board with component layouts on both the upper and lower surfaces. There are two transformers (Halo TG 110- EO 50N5), six inductive coils, multiple transistors, as well as many resistors, capacitors, and diodes, and over twenty integrated circuits, with U1 being a field programmable gate array. There is a socket connector on the top surface, and additional connectors, resistors, transistors, and capacitors on the bottom surface. The circuit board is drilled with mounting holes, and most components are labeled with reference identifiers for easy identification.
Application scenarios: Mainly used in gas turbine control systems, as well as other industrial automation scenarios with high requirements for analog input and output, such as power generation, oil and gas, manufacturing, and other fields.
