IS200EPSMG1AED Exciter power module
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IS200EPSMG1AED is an excitation machine power module designed by General Electric (GE) specifically for its EX2100 excitation system. Here is its detailed information:
Function and purpose: Installed in the EPBP backplane, it converts the 125VDC voltage of the EPDM board into the 5VDC, 15VDC, or 24VDC voltage required by the EX2100 control system, providing logic level power to other controllers and also supplying power to external modules, such as providing 24VDC power to the pry bar module, EDCF, EGDM, and EDEX demagnetization module, and providing 70VDC isolation power to the ECTB and EXTB modules for contact wetting, ensuring stable and reliable operation of the excitation system.
Technical specifications: The size is approximately 14.75cm × 9.50cm × 3.50cm, and the weight is approximately 0.8kg.
Product features: Provides stable and accurate power, with overcurrent, overvoltage and other protection functions, can prevent module and connected equipment from being damaged due to electrical faults, adopts a compact design, and can effectively utilize space in the EX2100 system cabinet.
Applicable fields: Mainly used in the excitation control field of power plants and power systems, such as thermal power plants, hydropower stations, etc. It is more common in various power generation facilities using GE EX2100 excitation system synchronous generators.
Hardware Design: The front panel includes seven LED lights labeled P5, P15, N15, P24A, P24B, N24B, and P70, as well as the GE logo and board identification number. There are large components on the board, such as a transformer with a frame, a large inductor labeled Bicron B9309 0912, and a smaller inductor coil L2. There are five transistors with heat sinks located directly behind the front panel, and four heat dissipation elements on the surface. High voltage electrolytic capacitors, axial electrolytic capacitors, metal film resistors, and carbon composite resistors are used. There are nine fuses, multiple integrated circuits, two test points, and two backplane connectors.
