IC698ACC701 is a power distribution module in GE PACSystems RX7i series, designed to provide reliable power management and distribution for the system. Here are its detailed specifications:
- Product Model: IC698ACC701
- Brand: GE Fanuc
- Series: PACSystems RX7i
- Function: Power distribution and management, supporting redundant configuration to enhance system reliability.
| Parameter |
Details |
| Input Voltage |
– Main power supply: 24VDC (with a fluctuation range of -20% to +25%)
– Standby power supply: 24VDC (optional) |
| Output Voltage |
5VDC (powers the backplane and modules). |
| Maximum Output Current |
12A (at 5VDC). |
| Power Consumption |
Approximately 25W (at full load). |
| Efficiency |
≥90%. |
| Operating Temperature |
-20°C to +60°C (storage temperature: -40°C to +85°C). |
| Humidity |
5% to 95% (non-condensing). |
| Vibration/Shock Resistance |
Compliant with industrial standards (IEC 60068-2-6/27). |
| Safety Certifications |
UL, CSA, CE, ATEX (Zone 2 optional). |
| Dimensions |
133mm × 100mm × 60mm (height × width × depth). |
| Weight |
Approximately 0.8kg. |
-
Redundant Power Supply Support
Supports dual power input (main power + standby power). It automatically switches to the standby power supply when the main power fails, ensuring uninterrupted system operation.
-
Power Monitoring and Diagnostics
- Built-in voltage monitoring circuit to real-time monitor input/output voltage status.
- Power status (normal/fault) is displayed via LED indicators.
- Supports remote monitoring of power health through the diagnostic tools of the RX7i system.
-
Hot-Swap Design
Supports on-line replacement, allowing maintenance or replacement of the power module without shutting down the system, reducing system downtime.
-
EMC Compatibility
Compliant with industrial-grade electromagnetic compatibility standards, reducing interference to other devices.
-
Short-Circuit Protection
Built-in overcurrent protection circuit that automatically cuts off the power supply in case of output short circuit to protect system safety.
- Industrial Automation: Provides stable power for RX7i controllers, I/O modules, and communication modules.
- Critical Control Systems: Suitable for scenarios requiring high reliability, such as power, chemical, and metallurgical industries.
- Distributed I/O Systems: Supports multi-rack expansion and powers remote I/O modules through the backplane.
- Redundant Configuration Systems: Works with redundant CPU modules to build high-availability control systems.
