IC693MDL340 output module
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IC693MDL340 is a 120V AC, 0.5A output module in the GE Fanuc 90-30 series. The following is its detailed information:
Basic parameters
Rated voltage: 120V AC.
Voltage range: 85-132V AC, 50/60Hz.
Output points: 16 points, divided into two groups, each with 8 points, isolated from each other.
Output current: maximum 0.5A per point, maximum 3A per group.
Electrical isolation
Isolation between on-site and logical side: 1500V.
Inter group isolation: 500V.
Protection circuit: Each group is equipped with a 3A fuse, and each output point has an RC buffer to protect against transient electrical noise on the power line.
Status indication: There is an LED indicator light at the top of the module, providing on/off status indication for each point. There are two rows of green LEDs, labeled A1-A8 and B1-B8 respectively, used to indicate the output status. There is a red LED (marked as F) in the middle to the right, which is a fuse blown indicator light. When any fuse is blown and the load is connected to the blown fuse, this indicator light will light up.
