The F650NFLF2G5HIP6E is a frequency inverter belonging to the Altivar Process ATV650 series by Schneider Electric. It is primarily used for motor speed control in industrial processes, suitable for loads such as pumps, fans, and compressors. Below is its detailed information:
- F650: Represents the Altivar Process ATV650 series inverter (designed for medium-to-high power industrial process applications).
- N: Indicates the rated supply voltage is 380-480V AC three-phase (compatible with common industrial three-phase power supplies).
- FL: Relates to the rated power specification (when combined with subsequent parameters, it typically corresponds to power levels of 15kW and above; specific details should be confirmed with the official manual).
- F2G5: Refers to the cooling method and compatible motor type (presumed to be fan-cooled and suitable for standard asynchronous motors).
- HIP6E: Denotes the protection class, control functions, and additional configurations (presumed to have an IP rating of IP21 or IP54, with basic control interfaces and EMC filtering).
- Supply Voltage: 380-480V AC three-phase, 50/60Hz (wide voltage adaptation, compatible with most industrial power grids worldwide).
- Rated Power: Depending on the model suffix, it typically ranges from 15kW to 75kW (specific values should be based on Schneider’s official manual, as different power levels correspond to different load adaptation capabilities).
- Output Current: Based on the power rating, the typical range is 30A-150A (continuous output current to ensure stable motor operation).
- Speed Regulation Range: 0.5-50Hz (or higher), supporting smooth adjustment from low to high motor speeds to meet variable flow requirements of pumps/fans.
- Overload Capacity: 110% of rated current for 60 seconds (to handle short-term load fluctuations and protect the motor and inverter).
-
Process Control Optimization
- Built-in PID regulator that can directly interact with sensors for pressure, flow, liquid level, etc., to achieve closed-loop control (e.g., automatically adjusting water pump speed to maintain constant water pressure).
- Supports multi-pump linkage control (up to 8 pumps), suitable for scenarios requiring redundancy or graded adjustment, such as water supply and sewage treatment.
-
Protection Functions
- Equipped with multiple protections including overcurrent, overvoltage, undervoltage, overheating, motor overload, and ground fault, reducing the risk of equipment damage.
- Supports motor thermal protection (monitors motor temperature via analog signals or temperature sensors to prevent overheating and burnout).
-
Communication and Interfaces
- Standard Modbus RTU communication interface; optional Profibus, EtherNet/IP, and other industrial bus modules (facilitating integration into PLC or SCADA systems for remote monitoring).
- Provides digital inputs/outputs (DI/DO) and analog inputs/outputs (AI/AO), which can be directly connected to external sensors or control buttons.
-
Energy Efficiency and Operational Characteristics
- Adopts vector control technology, maintaining high torque output even at low speeds (e.g., overcoming static resistance during fan startup).
- Features an automatic energy-saving mode that optimizes output voltage and frequency based on load changes, reducing energy consumption under no-load or light-load conditions (energy savings of 20%-50% compared to traditional fixed-speed operation).
