1. Basic Information

• Model: DSRF197K01
• Brand: ABB (Hitachi Energy)
• Type: I/O Subrack / Chassis
• Order No.: 3BSE019999R1
• Weight: Approx. 0.85 kg

2.Key Specifications

• Structure: Single 5V Regulator
• Slot / Mounting: Standard 19-inch rack mounting, compatible with ABB series I/O modules
• Power Supply: Backplane-powered, provides stable 5V DC output
• Environment: Industrial-grade design, operating temperature -20°C ~ +60°C
• Protection: IP20 (dust protection, finger protection)
• Certifications: CE / UL / RoHS compliant

3. Main Functions

Module Installation Carrier

• Provides standard mounting positions for I/O modules in ABB control systems
• Supports hot-swapping and modular expansion for easy maintenance and upgrade

Stable Power Supply

• Built-in 5V regulated power supply provides clean, stable DC power for all slot modules
• Features over-current, over-voltage, and short-circuit protection to ensure system safety

System Expansion

• Compatible with ABB systems including AC 800M, S800 I/O, DCS
• Can be combined with other racks and modules in the DSRF197 series to build a complete control station

4. Typical Applications

• Process Industry: Chemical, power, metallurgy, water treatment, papermaking
• System Type: ABB AC 800M DCS, S800 I/O, PLC control systems
• Usage: Centralized installation of I/O modules, system expansion, control cabinet integration

5. Summary
