ABB DSDP150 57160001-GF Pulse Encoder Input Unit

Basic Information

• Model: DSDP150
• Part Number: 57160001-GF
• Manufacturer: ABB (Sweden)
• Type: Pulse Encoder Input Unit
• Compatible System: ABB Advant Master / S100 / System 800xA
• Purpose: Precision Position / Speed / Length / Frequency Measurement

Technical Specifications

• Input Channels: 2 (A/B phase encoder)
• Max Pulse Frequency: 10 kHz
• Resolution: Up to 24 bits
• Accuracy: ±0.05% of full scale
• Input Voltage: 12–24 V DC
• Operating Voltage: 24 V DC (±10%)
• Operating Temperature: -20°C to +60°C
• Protection Rating: IP67
• Response Time: <10 µs
• Mounting: DIN Rail
• Dimensions: 360 × 15 × 250 mm
• Weight: 0.425 kg
• Certifications: CE, UL

Key Features

• High Precision: 24-bit resolution, 10 kHz max frequency
• Encoder Support: Incremental/absolute (A/B/Z phase)
• Fast Response: <10 µs for motion control
• System Integration: Seamless with ABB Advant Master / 800xA
• Diagnostics: LED status, fault detection, hot-swap

Applications

• Paper/Textile/Metal: Length, speed, tension control
• CNC/Machine Tools/Robotics: Position feedback
• Conveyors/Lifting/Elevators: Speed/position monitoring
• Power/Chemical/Water: Flow, speed, level measurement
