1. Part Number Meaning (ABB Naming Convention)
- 5SHY: Product series, indicating high-power IGCT modules
- 35: Rated current: 3500A (IGCT version)
- 45: Rated voltage: 4500V (4.5kV)
- L4512: Internal version and packaging code
2. Core Technical Specifications
- Type: Asymmetrical IGCT (Integrated Gate-Commutated Thyristor)
- Rated voltage: 4500V (4.5kV)
- Rated current: 3500A (DC)
- On-state voltage drop: 2V @ 4000A (low loss)
- Switching speed: Response time ≤ 1.2μs
- Operating frequency: <100Hz (low-frequency high-power applications)
- Operating temperature: -40℃ ~ +150℃
- Power loss: Total switching loss approx. 12kW
- Package: Industrial standard power module (with heat sink)
- Protection: Built-in overcurrent, overvoltage, short-circuit, and overtemperature protection
3. Key Features
Low Loss & High Efficiency
- Ultra-low on-state voltage drop (2V @ 4000A), significantly reducing system power consumption
- Microsecond-level switching speed, suitable for high-power low-frequency applications
High Reliability & Stability
- Wide operating temperature range (-40℃ ~ +150℃), adaptable to harsh industrial environments
- High electromagnetic compatibility (EMC), strong anti-interference capability
- Low leakage current, reducing unnecessary power loss
Integrated Design
- Integrated gate drive and protection circuits, simplifying system design
- Asymmetrical structure optimizing reverse recovery characteristics
- Supports series/parallel expansion, with power capacity up to 100MVA
4. Typical Applications
- High-voltage inverters (e.g., ABB ACS6000 series)
- Industrial drives: steel rolling, mining, fans, pumps
- Renewable energy: wind power, photovoltaic inverters
- Power grid equipment: High-Voltage Direct Current (HVDC) transmission, reactive power compensation
- High-power power supplies: induction heating, electrolysis, electroplating
5. Appearance & Structure
- Structure: Modular design, including main power chip, gate drive board, heat dissipation baseplate
- Dimensions: Approx. 250×350×150mm
- Weight: Approx. 1.6kg
- Interfaces: main power terminals (high current), gate control signal terminals
