VMIVME-7740-850 VMEbus single board computer
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
The VMIVME-7740-850 is a VMEbus single-board computer based on the Intel Pentium III processor. Below is a summary of content similar to a user manual, compiled from relevant information:
It features an Intel Pentium III processor in a PGA370 socket, with a maximum speed of 850MHz. The Pentium III processor offers 32-bit addressing and a 64-bit data bus. Its superscalar architecture allows execution of three instructions per clock cycle, and it includes a dynamic branch prediction unit, separate instruction and data caches, and MMX™ technology. It is equipped with 256Kbyte Advanced Transfer Cache (on-chip full-speed L2 cache).
Compatible with operating systems such as Windows 98 Second Edition, Windows NT/Windows 2000, Windows CE, Linux, VxWorks, QNX, Solaris, and LynxOS.
Accepts one 144-pin SDRAM SODIMM, with a maximum memory capacity of 512Mbyte. Onboard DRAM is dual-port connected to the VMEbus.
Supports Ethernet LAN via dual Intel 82559 Ethernet controllers, with two RJ45 connectors for 10BaseT and 100BaseTX options, and supports remote LAN booting.
Two 16550-compatible serial ports are located on the front panel. Each serial channel has a 16-byte FIFO and supports baud rates up to 56Kbyte/s. Two micro-DB9 to standard DB9 adapters (VMIC P/N 360-010050-001) are required.
The front panel includes a Universal Serial Bus (USB) connection, as well as PS/2 keyboard and mouse ports.
Can provide up to 192Mbyte of IDE CompactFlash storage, accessible via an auxiliary IDE port. The BIOS includes an option to allow the board to boot from flash memory.
Supports high-resolution graphics and multimedia-quality video through a Chips & Technology AGP graphics adapter. It is equipped with 4Mbyte internal synchronous DRAM and a high-bandwidth 64-bit data interface, supporting screen resolutions up to 1600×1200×64000 colors (single-view mode).
