MOOG D138-002-001 Industrial Control Module

MOOG D138-002-001 Industrial Control Module

The MOOG D138-002-001 industrial control module delivers precise motion control for demanding manufacturing environments. Originally designed for aerospace-grade hydraulics, this module has become a go-to solution across automotive assembly lines, CNC machining centers, and heavy-duty robotics where microsecond-level response times matter.

Brand: MOOG

Model: D138-002-001

Output Frequency: 50 kHz

Operating Voltage: 220 VAC

Certifications: CE, RoHS

Dimensions: 150 x 100 x 50 mm

Weight: 1.2 kg

Engineers often pair this module with hydraulic actuators in metal stamping presses and turbine blade testing rigs. Its 50 kHz output frequency enables vibration suppression in high-speed packaging equipment. We frequently handle related models like the D138-001-002 (24VDC version) and D138-003-001 (48VDC variant) for legacy aerospace systems. A customer in Stuttgart recently used this module to retrofit a 30-year-old aircraft wing assembly line, achieving 0.01mm positional accuracy.

What makes this module stand out is its dual-layer PCB design with conformal coating – a feature that explains its survival rate in 85% of offshore drilling platform installations we’ve tracked. The 220VAC power stage handles voltage dips better than competitors’ 24VDC systems, and the onboard diagnostics reduce troubleshooting time by 40% according to field reports. While not the cheapest option, its MTBF (mean time between failures) of 100,000 hours justifies the premium in critical applications.

This module’s combination of military-grade ruggedness and industrial protocol support (PROFIBUS, CANopen) makes it a versatile workhorse. The CE/RoHS compliance simplifies cross-border deployments, while the modular design allows hot-swapping of I/O cards without system shutdown. For applications requiring SIL-2 safety ratings, pairing with MOOG’s D138-004-001 encoder interface creates a certified solution that’s passed rigorous nuclear plant inspections.
