IS220PRTDH1A RTD input module
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IS220PRTDH1A is a resistance temperature device (RTD) input module manufactured by General Electric (GE), belonging to the Mark VIe series, used in distributed control systems. Here is its detailed information:
essential information:
Part number: IS220PRTDH1A
Manufacturer: General Electric (GE)
Series: Mark VIe
Product type: RTD input module
Performance parameters:
Number of channels: 8 channels
A/D converter resolution: 14 bits
Common mode voltage range: ± 5 volts
Maximum lead resistance: 15 Ω maximum
Input range: -200 ° C to 800 ° C (-328 ° F to 1472 ° F)
Resolution: 0.01 ° C (0.02 ° F)
Functional features:
It can work in conjunction with RTD input terminal boards (such as IS200TRTDH2D, IS200SRTDH1A, or IS200SRDDH2A, etc.) and can be used in hazardous areas in some cases.
The front panel has LED indicators for two Ethernet ports of the I/O unit, as well as power and ATTN LED indicators.
Each I/O pack has dual 100mb full duplex Ethernet ports that can digitize sensor signals and feed them to the controller.
The H1D version provides filtering functionality compatible with the PRTD standard scanning rate (as mentioned in some sources).
