IS220PDIAH1BE digital input module GE

IS220PDIAH1BE digital input module

Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!

Product Overview

Technical Parameters

• Input Type: Discrete digital input (supports dry contact or wet contact signals).
• Number of Input Channels: Typically includes 16 or 32 independent digital input channels (subject to the actual model).
• Input Voltage Range: 24V DC (typical value, suitable for industrial standard DC signals).
• Input Current: Maximum 5mA per channel (active state).
• Response Time: ≤10ms (delay from signal input to processor recognition).
• Isolation Method: Electrical isolation between channels (prevents signal interference and improves system stability).
• Operating Temperature Range: -40°C to +70°C (adapts to harsh industrial environments).
• Storage Temperature Range: -40°C to +85°C.
• Protection Rating: IP20 (suitable for installation in control cabinets).
• Dimensions: Conforms to the standard size of Mark VIe series, approximately 160mm × 100mm × 50mm (subject to the actual product).
• Weight: Approximately 0.3kg.

Functional Features

1. Highly Reliable Signal Acquisition
   • Supports multi-channel parallel input, enabling simultaneous collection of switch states from multiple external devices (such as on-off signals of valves, relays, sensors, etc.).
   • Equipped with anti-electromagnetic interference (EMI) design, adapting to complex electrical environments in industrial sites and ensuring the accuracy of signal acquisition.
2. Diagnosis and Status Indication
   • The front panel of the module is equipped with LED indicators, respectively indicating power status (Power), channel activation status (each channel has a corresponding indicator), and fault alarm (Fault), facilitating quick troubleshooting.
   • Supports online diagnosis function, which can monitor abnormal states such as channel faults and disconnections through system software and feed them back to the main controller.

1. System Compatibility
   • Seamlessly integrates into the GE Mark VIe control system, communicating with main controllers (such as UCV, ICV modules) through the backplane bus to realize real-time data upload.
   • Compatible with GE Proficy Machine Edition and other configuration software, allowing users to configure input parameters and monitor channel status.
2. Industrial-Grade Design
   • Adopts a robust metal housing, resistant to vibration and impact, complying with industrial environment reliability standards (such as IEC 61010-1).
   • Supports hot-swappable function (requires system redundancy configuration), enabling module replacement without interrupting system operation, reducing downtime.

Installation and Wiring

• Installation Method: Fixed in the standard rack of the Mark VIe control cabinet via guide rails or screws, and directly connected to the backplane bus connector for power supply and communication.
• Wiring Method: Uses pluggable terminal blocks (usually Phoenix terminals), with each channel corresponding to “+” and “-” terminals, facilitating on-site wiring and maintenance.
• Notes: Before wiring, ensure that the input voltage matches the rated value of the module to avoid damage due to overvoltage; signal lines should be laid separately from power lines to reduce interference.
