IS215VCMIH2CA VME communication interface card
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IS215VCMIH2CA is a VME communication interface card in the GE Speedtronic Mark VI gas turbine control system. The specific information is as follows:
Function: Serve as a link between the I/O board and controller, as well as a communication interface for IONet (System Control Network), allowing input/output (I/O) cards to communicate with other I/O cards, I/O backup protection modules, triple redundant control modules, and main processor modules.
Hardware Design:
Processor: Using TI 32-bit digital signal processor chip.
Connector: The front panel integrates four port connectors, including an RS-232C serial port, a D-type plug connector, and three IONet 10Base2 Ethernet connectors. In addition, there are two backplane connectors, a 12 pin vertical connector, and other conductive connectors.
Indicator lights: There are multiple LED indicator lights, with three LED lights labeled TX/RX/CD associated with each IONet port, as well as Status, Fail, Run, and 1, 2, 4, and 8 indicator lights used to display device operating status and other information.
Integrated Circuit: Contains over 50 types of integrated circuits, such as oscillation chips, and is equipped with three transformer components. By using inductive magnetic beads, high-frequency noise on the circuit board can be reduced.
