IS210SAMBH2AA Printed Circuit Board for Mark VI Control System Design
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IS210SAMBH2AA is a printed circuit board (PCB) designed by General Electric (GE) specifically for Mark VI control systems, primarily used in automation control scenarios for gas or steam turbines. Here is its detailed information:
1、 Function and purpose
As a key component of the Mark VI system, IS210SAMBH2AA mainly undertakes the following functions:
Communication and Data Interaction
Supports multiple communication protocols, including Modbus RTU Slave, SNP Slave, etc., and can exchange data with other devices or systems through RS-232 (COM1) and RS-485 (COM2) interfaces. Some information shows that it supports Ethernet communication (such as SRTP and Modbus TCP/IP) and can achieve real-time data transmission.
Signal Processing and Control
Provide 18 dynamic pressure input channels and 18 buffer output channels for monitoring the combustion dynamic pressure signals of gas turbines, and transmit the processed signals to the central control module. Both input and output are integrated with noise suppression circuits, which can resist high-frequency interference.
System Expansion and Compatibility
As an auxiliary board, it is fixed to the motherboard with four screws, providing additional processing power or dedicated function expansion for the Mark VI system.
