ICS TRIPLEX TC-201-01-4M5 is a high-performance digital output module designed for industrial automation and control systems. Here are its detailed specifications:
- Brand: ICS TRIPLEX (now a brand under Schneider Electric)
- Model: TC-201-01-4M5
- Type: Digital Output Module (DO Module)
- Application Scenarios: Suitable for safety-critical control systems (such as ESD, F&G, BMS) in industries like oil and gas, chemical engineering, electric power, and metallurgy.
-
Electrical Specifications
- Operating Voltage: 24VDC (typical value, supporting ±15% fluctuation)
- Output Type: Transistor output (dry contact)
- Number of Output Channels: 16 channels
- Output Frequency: 4MHz (high-speed pulse output)
- Contact Capacity: 2A per channel (resistive load)
- Isolation Method: Optocoupler isolation, with mutual isolation between channels
-
Performance Indicators
- Response Time: ≤1ms (typical value)
- Resolution: 1ms
- Accuracy: ±0.1% (full scale)
- Operating Temperature: -40°C ~ +70°C
- Storage Temperature: -55°C ~ +85°C
- Humidity: 5% ~ 95%RH (no condensation)
- Protection Rating: IP20 (module), must be installed in a control cabinet
-
High Reliability
- Adopts Triple Modular Redundancy (TMR) architecture, supporting fault tolerance and online maintenance
- Complies with IEC 61508 SIL 3 safety level requirements and has passed TÜV certification
- Built-in self-diagnostic function for real-time monitoring of module status
-
Flexible Configuration
- Supports hot swapping, allowing online replacement of faulty modules
- Channels can be independently configured as active high or active low
- Supports SOE (Sequence of Events) function with a time resolution of ≤1ms
-
Communication Interfaces
- Supports protocols such as Modbus RTU/TCP, Profibus DP, and HART
- Can communicate with other modules via TRICONEX dedicated network
Warranty： 365 days
Quality: Original module
Condition： New / Used
Warehouse: Spot
Delivery time: Shipped in 3 days after payment
