IC698CHS117C 18 slot I/O rack

IC698CHS117C 18 slot I/O rack

---



Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!









IC698CHS117C is an 18 slot I/O rack in the GE Fanuc Rx7i PACsystem series. The following is its detailed information:
overview
This rack is designed specifically for VME64 backplane systems and advanced power supplies, suitable for wall mounted installation, providing installation and electrical connections for I/O modules in GE Fanuc PLC systems. It supports Rx7i CPUs, Rx7i I/O modules, series 90-70 I/O, and all standard VME modules, meeting the needs for I/O capacity expansion in industrial applications.







technical specifications
Electrical specifications:
Power requirements: Typically, an Rx7i power supply is used, with a rated power of 350 watts and support for multiple input voltages. The rated current is 4 amperes at -12 volts, 12 amperes at 12 volts DC input, and 60 amperes at 5.0 volts DC input.
Working voltage: usually 5 to 12 volts DC.
I/O capacity:





Number of slots: A total of 18 slots, of which slot 0 is a power slot with a width of 2.6 inches, used for installing Rx7i power modules; Slot 1 is usually used for installing CPUs. If it is a dual width module such as IC698CPE010/020 and IC698CRE020 CPU with Ethernet sub card, it will occupy slots 1 and 2. The remaining 16 slots can be used to install I/O modules, supporting up to 15 single width I/O modules (excluding any double width modules), 8 double width modules, or a combination of double width and single width modules, with an average slot width of 0.8 inches.





Related products：

---
