IC697CPX772 Single slot CPU module
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IC697CPX772 is a single slot CPU module from the former General Electric (GE) Fanuc 90-70 series under Emerson Automation. The following is its detailed information:
hardware performance
Processor: Equipped with a 96MHz 80486 DX4 microprocessor, with a Boolean processing speed of 0.4 microseconds and support for floating-point calculations.
Memory: It has 512KB of slow battery backup RAM for storing user data, programs, configurations, and register data, as well as 256KB of non-volatile flash memory for storing user data and firmware.
function characteristics
I/O support: Supports configuring up to 2k of any combination of inputs and outputs, as well as up to 8k of analog I/O, which can be used in conjunction with IC660/IC661 I/O and IC697 I/O modules.
Communication Interface: Equipped with three serial ports, including one RS-232 RJ11 serial port and two 9-pin D-type RS-485 communication interfaces, supporting SNP slave, Break free SNP, SNPX, and RTU serial protocols.
Status indication: The front panel has seven green LEDs used to indicate the status of the CPU, including toggle switch position, memory protection, serial port activity, and program status.
Configuration method: No jumper or DIP switch required, configured through MS-DOS or Windows based programming software, with reference information in the front panel, firmware upgradable within the system, and other features.
