IC693PWR321 Power module
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IC693PWR321 is a standard power module in the General Electric (GE) Fanuc 90-30 series. The following is its detailed information:
Basic function: Provides stable power supply for GE Fanuc 90-30 series PLC systems, compatible with any CPU model in the series, supports simplex, fail safe, and fault-tolerant functions.
Input characteristics:
Rated input voltage: 120/240V AC or 125V DC.
Input voltage range: 85 to 264V AC or 100 to 300V DC.
Input power: 90VA for AC input and 50W for DC input.
Output characteristics:
Load capacity: 30W.
Output voltage: Provides one+5V DC output and two+24V DC outputs. One of the+24V DC is the relay power output, used to power the circuit of the 90-30 series output relay module; The other is isolated output, which is used internally by some modules and can also provide external power for 24V DC input modules.
Other features:
Protection function: It has a current limiting function, which will cut off the power supply when a direct short circuit occurs to protect the hardware.
Diagnostic function: Equipped with advanced diagnostic functions and built-in intelligent switch melting function, it improves performance and safety during use.
