IC693MDL655 Positive/Negative Logic Input Module
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IC693MDL655 is a 24V DC positive/negative logic input module in the General Electric (GE) Fanuc 90-30 series. The following is its detailed information:
Basic function: Provide 32 discrete inputs for GE Fanuc 90-30 series PLC, which are divided into four groups of 8 points each. Each group is isolated from each other and shares a common terminal at 8 o’clock.
Rated voltage: 24V DC.
Input voltage range: 0V to -30V DC.
Electrical isolation: The isolation between the field side and the logic side is achieved through optocouplers, and each group of inputs is also isolated from each other, enhancing the stability and anti-interference ability of the system.
Input characteristics: The input current is 7.0mA, the on state voltage is 11.5V to 30V DC, and the off state voltage is 0V to+5V DC.
Connection method: There are two 24 pin male plugs in front of the module, with the right plug providing interfaces for group A and B inputs, and the left plug providing interfaces for group C and D inputs. Users need to use a cable with tin plated wire on one end and a matching female plug on the other end to connect the input device to the input circuit. Pre wired cables such as IC693CBL327 and IC693CBL328 can be selected.
