IC693MDL645 Positive/Negative Logic Input Module
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
IC693MDL645 is a 24V DC positive/negative logic input module in the GE Fanuc 90-30 series. The following is its detailed information:
Basic function: Provide 16 discrete inputs for GE Fanuc 90-30 series PLC, which are configured as a group with a common power input terminal.
Rated voltage: 24V DC.
Input voltage range: 0V to 30V DC.
Electrical isolation: The isolation voltage between the on-site side and the logic side is 1500V.
Input characteristics: The on state voltage is 11.5V to 30V DC, and the off state voltage is 0V to 5V DC; The typical input current is 7mA at rated voltage, with a maximum current of 3.2mA in the on state and 1.1mA in the off state; the typical on and off response times are both 7ms.
Power consumption: At 5V, when all inputs on the 5V bus of the backplane are conductive, it is 80mA; at 24V, it is 125mA from the isolated 24V backplane bus or user provided power supply.
Compatibility: Its input characteristics enable it to be compatible with various input devices, such as buttons, limit switches, and electronic proximity switches. When current flows into the input point, it is identified as logic 1 in the input state table (% I).
