The IC693CPU363 is a CPU module in the GE Fanuc Series 90-30. Here are its detailed specifications:
-
Basic Parameters:
- Processor: Equipped with an 80386EX processor with a main frequency of 25MHz.
- Memory: 240KB of user memory.
- I/O Points: Supports 2048 digital inputs and 2048 digital outputs.
- Serial Ports: Features 3 serial ports, compatible with RS-232 and RS-485 communication standards.
- Operating Temperature: Operates within a temperature range of 0°C to 60°C.
-
Functional Features:
- Powerful Communication Capabilities: The 3 serial ports of the module can support protocols such as SNP, SNPX, and RTU. Among them, the serial port accessible through the power connector is a 15-pin D-type female connector, which can be connected to a programming PC or a handheld programmer and supports the SNP/SNPX slave protocol. The other two ports support SNP/SNPX master/slave and RTU slave protocols, and can also support Ethernet and Profibus communication via optional modules.
- Relatively Fast Scanning Speed: The typical scanning rate for Boolean contacts is 0.22 milliseconds per 1KB of logic. It can process programs quickly and respond to input and output signals in a timely manner, meeting the real-time requirements in industrial control.
- Support for Multi-Rack Expansion: It can handle up to 8 backplanes and support up to 7 remote or distributed I/O. It can connect multiple expansion modules, making it easy to expand the system scale according to actual needs and adapt to industrial control scenarios of varying complexity.
- Battery Backup Function: A battery is provided for clock backup, which can keep the clock running normally even in the event of a power outage, ensuring the accuracy of the system time. Meanwhile, the battery function can be overridden by settings.
-
Application Fields: With its excellent performance, the IC693CPU363 is widely used in industries such as manufacturing, electric power, chemical engineering, metallurgy, building materials, and food. It can be applied to industrial automation control scenarios such as production line control, process control, and motion control.
