IC660EPM100J is an electronic component in GE Fanuc’s Genius I/O series. Here are its detailed specifications:
-
Product Type: Electronic component, specifically a Genius PowerTrac module.
-
Function and Purpose: It performs logical and mathematical functions for Genius I/O modules. It monitors current and voltage inputs, stores the digitized waveform values of each input, and then calculates parameters such as kilowatt-hours, current, active power, RMS voltage, reactive power, and power factor. The calculated data is automatically sent to the host PLC or computer.
-
Operating Temperature: 32°F to 140°F (approximately 0°C to 60°C).
-
Storage Temperature: -40°F to 212°F (approximately -40°C to 100°C).
-
Relative Humidity: 5% to 95%, non-condensing.
-
Power Input: Supports 115/230VAC or 125VDC input.
-
Applicable Power Supply Systems: Can be used with single-phase power supply systems or three-phase power supply systems in delta configuration.
-
Input Connections: Accepts voltage inputs from 1 to 3 voltage transformers, as well as current inputs from up to three line current transformers and one neutral current transformer.
-
Installation Method: It needs to be connected to a compatible terminal assembly for use. It can be easily inserted into or removed from the terminal assembly without interfering with the wiring of the I/O module. It can be installed on a Genius bus up to 7,500 feet away from the host computer or PLC, and can also be used in standalone applications without a host.
