DS200UDSAG1ADE Digital Input Module for Mark V Series Gas Turbine Control System Design
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
DS200UDSAG1ADE is a digital input module designed by General Electric (GE) for the Mark V series gas turbine control system. It is mainly used to collect switch signals and transmit them to the control system. Here is its detailed information:
Basic information
Product model: DS200UDSAG1ADE
Manufacturer: General Electric (GE)
Application areas: Mark V gas turbine control system, industrial automation switch signal acquisition
Module Type: Digital Input Module (DI Module)
Technical Parameter
Channel
There are a total of 16 digital input channels, supporting dry or wet contact signals.
Each channel has independent optoelectronic isolation, with an isolation voltage of ≥ 500V AC and strong anti-interference ability.
signal type
Input voltage range: 24V DC (typical value), supports 16-30V DC wide range input.
Logic level: High level (≥ 16V DC) represents “1”, low level (≤ 5V DC) represents “0”.
Functional Features
Isolation and protection
Electrical isolation between channels to avoid signal crosstalk; Equipped with overvoltage protection (such as transient suppression) to prevent external interference from damaging the module.
diagnostic function
Support online diagnosis, can detect channel open circuit, short circuit or power failure, and the fault indicator light (red) on the module will light up when there is a fault.
Support self testing function, triggered by control system software to verify the working status of the module.
