DS200TBQDG1AFF Extended Analog Terminal Board in Mark V DS200 Series
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
DS200TBQDG1AFF is an extended analog terminal board in the Mark V DS200 series from General Electric (GE), used for the GE RST system. Here is its detailed information:
Functional features:
Analog signal processing: provides additional analog input and output channels for the GE RST system, enhances system functionality, and can process multiple analog signals to meet the signal control and monitoring needs of different industrial scenarios.
Configurability: There are 2 jumper wires, and the operator can modify the behavior of the drive by changing the jumper settings, such as stopping or starting the motor, changing the direction and speed of the motor, etc., increasing the flexibility and operability of the system.
Testing function: Equipped with 3 testing points with IDs TP1, TP2, and TP3, qualified service personnel can use these testing points to test various circuits of the board for easy troubleshooting and maintenance.
Hardware specifications:
Terminal block: There are 2 terminal blocks, each containing 107 signal line terminals, used to connect signal lines and achieve signal transmission with other devices.
