DS200CTBAG1ADD Terminal board designed for Mark V Speedtronic system
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
DS200CTBAG1ADD is a terminal block designed by General Electric (GE) for its Mark V Speedtronic system, belonging to the Mark V DS200 series. Here is its detailed information:
Functional purpose: It is an analog terminal module used to receive and send analog signals in the GE MARK V system, providing safe and efficient connections for components in the system, ensuring smooth communication and operation within the system. Widely used in industrial equipment, power plants, and other scenarios where GE MARK V systems are used.
Hardware Design:
Appearance structure: It is a long and narrow board with drilled holes at each corner and long edge for installing hardware and other connections. The board is marked with an identification code, including the board ID number and company logo.
Connectors: It has multiple connectors, including two COREBUS connectors (JAI and JAJ), two double-layer terminal blocks located on one long edge of the board, with multiple connectors on each terminal block, as well as five vertical pin cable connectors, two vertical pin connector connectors, and one 9-pin male serial connector.
