Allen-Bradley 1336-BDB-SP53C Control Module

Allen-Bradley 1336-BDB-SP53C Control Module

Engineered for demanding industrial environments, the 1336-BDB-SP53C Control Module delivers precise motor control and adaptive performance across automation systems. Its rugged design handles voltage fluctuations common in heavy machinery settings, making it a go-to solution for maintaining production uptime.

Technical Specifications

Brand: Allen-Bradley
Model: 1336-BDB-SP53C
Voltage: 220 V AC input range
Output: 30 kHz switching frequency
Compliance: UL/CE certified
Series: 1336-BDB
Origin: USA-manufactured
Order Minimum: Single unit available

Found extensively in packaging lines and conveyor systems, this module excels where precise torque control matters. A Midwest automotive plant recently upgraded their stamping presses using this model, achieving 15% energy savings. Our inventory also supports legacy systems through compatible models like the 1336-BWA06-AE50 and 1336-BA06-AA-ES.

What sets this module apart is its adaptive thermal management – I’ve seen installations in steel mills maintain stability at 55°C ambient temps. The modular bus architecture simplifies field replacements, and dual-channel diagnostics reduce troubleshooting time by 40%. Compatible with DeviceNet networks and Rockwell’s Studio 5000 environment, it supports seamless integration with newer ControlLogix systems.

In real-world applications, this module proves its worth through consistent performance under vibration-heavy conditions. The quick-replacement fuse design cuts downtime during unexpected surges, while the onboard signal conditioning handles 12-pulse rectification without external filters. For operations needing reliable motor control with minimal maintenance, this module remains a trusted industry standard.
