531X301DCCAFG2 Drive Control Board
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
531X301DCCAFG2 is a core component of the Mark V series drive control card produced by GE. It is a drive control board that integrates drive control, data acquisition, and processing functions.
- Power Supply Voltage: 24V DC or 250V AC.
- Rated Current: 1A or 5A.
- Communication Interface: Supports RS-485 protocol.
- Input/Output Signals: Supports digital and analog signals.
- Dimensions: Approximately 10cm × 5cm × 2cm.
- Weight: Approximately 1.25 kg.
- Operating Temperature Range: -40°C to 85°C.
- Control Function: Controls motor speed, torque, and other parameters by adjusting input voltage or current, enabling precise control of motors or other actuators (e.g., starting, stopping, accelerating, decelerating).
- Protection Function: Equipped with overcurrent, overvoltage, and overtemperature protection. It can also protect high-voltage transmission lines from faults such as short circuits and overloads.
- Other Features: Adopts a modular design for easy expansion and customization; has fast response and data processing capabilities; supports function expansion through firmware updates.
Widely used in industrial automation, process control, manufacturing, transportation, aerospace, etc. It can be used for motor control in production lines, monitoring of process equipment in the chemical industry, control of railway train drive systems, and protection of high-voltage transmission lines.
The Mark V panel can draw power from multiple sources, including one 125V DC power supply and/or up to two 120/240V AC power supplies. Each power input source should be connected to the Mark V panel through a separate external 30A 2-pole thermal-magnetic circuit breaker. A common 125V DC panel distribution bus supplies power to each power board in the panel.
Related products：
531X307LTBAJG1 Terminal board 531X series
