140ACI04000 Analog input module
- Module Type: Analog input module.
- Number of Channels: 16-channel differential input.
- Input Range: Supports input ranges such as 0 – 20mA, 0 – 25mA, and 4 – 20mA, with flexible configuration options.
- Resolution: 0 to 4095 counts (for 4 – 20mA input), capable of accurately capturing tiny current changes.
- Accuracy: The maximum absolute accuracy error is only ±0.125% of the full scale, with minimal linear error.
- Filter Characteristics: Single-pole low-pass filter with a 3dB cutoff frequency of 34Hz (±25%), which can effectively reduce noise.
- Signal Isolation: Strong isolation performance between channels and between channels and the bus, able to withstand up to 1780VAC for 60 seconds. The common-mode rejection ratio is greater than -90dB at 60Hz, which can reduce interference.
- Fault Detection: Equipped with 16 red LEDs to indicate channel faults, 16 green LEDs to indicate channel activation, and a separate LED to indicate external faults and bus communication status, facilitating fault diagnosis.
- Power Consumption: Only 5 watts, energy-efficient.
- Operating Temperature: The operating temperature range is generally -40°C to +70°C, and the storage temperature is -55°C to +85°C. Humidity is 5% – 95%RH (no condensation).
- Installation Method: Usually installed on a standard DIN rail, easy to integrate into industrial control systems.
Warranty： 365 days
Quality: Original module
Condition： New / Used
Warehouse: Spot
Delivery time: Shipped in 3 days after payment
