5SHY42L6500 is an integrated gate commutated thyristor (IGCT) from ABB. The following provides detailed information about it:
Basic information:
Type: Asymmetrical IGCT.
Release time: 2010.
Packaging: The packaging form is the same as that of some products in the same series, with a copper pole piece diameter of 85mm.
Electrical parameters:
Rated voltage: 6.5kV.
Maximum current: approximately 2.03kA.
Performance characteristics:
Low switching loss: After optimization, it features lower switching loss, which can improve energy utilization efficiency and reduce energy loss during equipment operation.
High Reverse Blocking Safe Operating Area (RBSOA): It maintains a high RBSOA even under high current change rates (di/dt), enabling stable operation in complex electrical environments and enhancing the reliability and stability of the device.
Resistance to cosmic radiation: With the ability to resist cosmic radiation, it can be used in some application scenarios that are sensitive to radiation, ensuring the stability of device performance.
Application areas: IGCT is suitable for industrial drives, railway power supply, power quality improvement, and high-current circuit breakers. As one of its members, 5SHY42L6500 can also be applied to these high-power scenarios.
