5SHY40L4511 is a press-fit integrated gate commutated thyristor (IGCT) from ABB. The following are its detailed specifications:
Basic information:
Control mode: BTG (Bidirectional Thyristor).
Pins and polarity: Three poles.
Packaging method: ceramic packaging.
Current capacity: high power.
Turn-off speed: high frequency (fast).
Shape: Flat-type.
Electrical parameters:
Commutating voltage: 2.8kV.
Maximum current: 3.6kA, optimized for medium-frequency switches.
Rated output active power: 10MW.
DC bus voltage: 5.6kVDC.
Rated primary voltage: 3.3kVrms.
Rated line-to-line grid voltage: 20kVrms.
Rated phase current: 1750Arms.
Carrier frequency: 800Hz.
Application areas: This device can be used in medium and high voltage frequency conversion, power electronic converters, and other fields. For example, in wind power converters, it can serve as a key power switching device to achieve the conversion and control of electrical energy.
